Category " QRO/QRP"

Easy to operate The overall operation of ACOM 2020S is extremely simplified: the touch screen menus are intuitive and easy to follow, no special skill is required from the operator when changing frequency bands. User-friendly automatic control When connected to a transceiver with CAT capability, the amplifier will track the operating frequency, and will change bands accordingly. Even if not CAT connected,...


Continue Reading »

httpvh://youtu.be/x3qQQP22VVY Take your contesting experience to the next level with the latest LDMOS power device with features supporting a SO2R operation in one amplifier. Features: 1kW output at fully duty cycle, even for extended periods of time Six antenna connectors allow customers to use a variety of antennas for multiple bands Connect to an ICOM radio and all settings are automatically...


Continue Reading »

General Features: Output Power 1.8 – 30 MHz   2K+, 6m 1K+ Device: 2x BLF189XR Auto Band Selection ICOM®; YAESU® Band data Interface CAT Connectivity LAN Connectivity Wi-Fi Connectivity Quiet Internal PSU 110-260V AC / 3KW up to 1K at 110V AC; full power at 230V AC internal Automatic Antenna Tuner (optional) 1x TRX and 4x Antenna Precise power meter from...


Continue Reading »

1.8-70MHz Solid State Linear Amplifier 1200W output 1.8-30MHz (1000W 50MHz, 500W 70MHz) Drive level 50W (10W/25W optional) Fully automatic band selection 3 antenna sockets Vacuum relay QSK switched Dual BLF188XR LDMOS Touch screen full colour display Network connected remote operation Quiet temperature controlled fans +10dBm pre-distortion output 100-260V...


Continue Reading »

The ACOM team, are proud to introduce the brand new 2020S. Solid-State 1500 W: 1.8-54 MHz Linear Power Amplifier with Touch-Screen Remote Control. The amplifier employs two powerful modules in power splitting/combining technique which is well time-proven in high-power commercial applications to provide sufficient output headroom. Thanks to input and output ports isolation from each other, the intermodulation...


Continue Reading »

The "QCX+" (QRP Labs Xcvr +): a feature-packed, high performance, single band 5W CW transceiver kit with WSPR beacon and built-in alignment and test equipment. Available for 80, 60, 40, 30, 20 or 17m bands. Experimental use on 15, 12, 10 or 6m (lower power output and reduced sensitivity). For complete details see http://qrp-labs.com/qcxp The Optional enclosure is black anodized extruded...


Continue Reading »

The "QDX" (QRP Labs Digital Xcvr): a feature-packed, high performance, four-band (80, 40, 30, 20m) 5W Digi-modes transceiver kit, including embedded SDR receiver, 24-bit 48 ksps USB sound card, CAT control, synthesized VFO with TCXO reference. QDX transmits a SINGLE SIGNAL, it is not an SSB modulator with associated unwanted sideband and residual carrier, or intermodulation due to amplifier non-linearity....


Continue Reading »

simple "digital" monoband transceiver SDT21 The goal of this project was the development of a simple to build CW monoband transceiver based on the direct superheterodyne principle with crystal control a la "PIXIE" or "Rockmite", but with much better technical data. To minimize the circuit effort, the concept should be as highly integrated as possible and realizable without hand-wound coils....


Continue Reading »
