| Frequency range | 10kHz-3,5GHz |
| Frequency resolution | 1Hz |
| Switching time | 10ms (100 steps/sec.) |
| Frequency accuracy | 10MHz reference intern: |
| Demodulators | AM, FM, USB, LSB, CW |
| Audio |
1,0 watt at 8 Ohm – 1% THD |
| IF-filter switchable | 2,4/ 4,0/ 6,0/ 15,0/ 30,0/ 110/ 220kHz optional 500Hz |
| IF-out | Switchable: on/off10,7MHz BW = 10MHz10,7MHz BW = 10,7MHz IF-filter455kHz BW = IF-filter |
| Typ. Sensitivity | 2-30MHz SSB 0,4µV, 10dB S/N, BW 2,4kHz AM 1,3µV, 10dB S/N, BW 6,0kHz>30MHz SSB 0,3µV, 10dB S/N, BW 2,4kHz FM 0,4µV 12dB SINAD, BW 15kHz |
| Immunity to interference |
IP? >+2dBm 18 Preselector-ranges |
| Lineare dynamic | >115dB |
| Pre-amplifier | 20dB in the frequency range |
| Attenuator | |
| Operation power | DC 12,0 volt 25 watt |
| Temperature range | -10° – +55°C |
| Sockets | ANT: BNC IF: BNC 10MHz REF: BNC |
| Case | metal |
Price: 3 959.00 ? (inkl. 19 % MwSt.)
