Carried out by an external PC control, LAN (1000BASE-T)
Possible Remote Control.
It can be recorded in up to 10MHz band RF signal received
Various signal analysis is possible.
Adopt direct sampling method
The digital conversion directly received RF signal, Zeng all processing
Implemented in software.
Equipped with a receiving section of the two systems
Wide band input suitable for wide band signal monitoring, detailed solution
Equipped with a receiving part of 2CH of narrow band input suitable for analysis.
The realization (3) high sensitivity and high dynamic range
Configuration of the AMP circuit, distortion of each element element, the filter circuit, etc.
Review the characteristics and achieve low noise and high dynamic range.
Equipped with (4) Digital IQ base band signal output
Equipped with a digital IQ data output of up to 10MHz width, each
Possible species waveform analysis.
19-inch rack built-in support
The mounting base for mounting to a 19-inch rack receiver body
And available as an option, and a wide range of equipment request.
