RF Performance

RF Power – MS Power Class 4 (1W)
RF Power – customisable for TMO/DMO/REP
Adaptive Power Control Supported
Receiver Class – A and B
Receiver Static Sensitivity -112dBm
Receiver Dynamic Sensitivity -103dBm

International IECEx Specifications

Gas Environment:
Protection by Intrinsic Safety: ib (one countable fault)
Gas Group: IIC (and all lower groups IIB and IIA)
Temperature: T4 (135 °C and all lower groups T3, T2 and T1)
Equipment Protection Level: Gb (Gas Zone 1 and 2)
Dust Environment:
Protection by Intrinsic Safety: ib (one countable fault)
Dust Group: IIIC (conductive dust and all lower groups IIIB and IIIA)
Equipment Protection Level: Db (Dust Zone 21 and 22)
Enclosure rated to:IP6x (Dust tight enclosure)

European ATEX Specifications

Gas Environment:
ATEX directive 94/9/EC
Equipment Group: II
Equipment Category: 2 (Suitable for use in Zone 1 and 2)
Protection by Intrinsic Safety: ib (one countable fault)
Gas Group: IIC (Hydrogen and the lower classes including; IIB – Ethylene; and IIA – Propane)
Temperature: T4 (135 °C and all lower groups T3, T2 and T1)
Equipment Protection Level: Gb (Gas Zones 1 and 2)
Dust Environment:
Equipment Group: II
Equipment Category: 2 (suitable for use in Zone 21 and 22)
Protection by Intrinsic Safety: ib (one countable fault)
Dust Group: IIIC (conductive dust and all lower groups IIIB and IIIA)
Equipment Protection Level: Db
Enclosure rated to:IP6x (Dust tight enclosure)

Product Performance

Audio Power 1 Watt *****
Operational Temperature -20°C to +55°C
Storage Temperature -40° to +85°C *
Dust & Water Protection IP67
Shock, Drop & Vibration ETS 300 019

* As defined in ETSI EN300 019-2-1 and EN300 019-2-2

***** Using internal STP8X speaker
Product Options

GPS
Micro SD Card (Up to 32Gb supported)
Man-Down Alarm***
DMO Repeater Type 1A
Air Interface Encryption Options
End to End Encryption Options
Wide Range of Languages supported

*** The Man-Down Alarm should in no way be regarded as a substitute for compliance with appropriate risk assessment and other safety procedures and practices. To enable Man-Down, a Software License is also required.
Voice Services

Full Duplex Calls (to MS and PABX/PSTN)
Half Duplex Calls (Individual and Group)
Priority Call
Emergency Call (Pre-emptive Priority)
Intelligent Alarm Reporting
Talking Party Identity
Calling Line Identity Presentation
DTMF Dialling ****
MSISDN Dialling ****
Dynamic Group Number Assignment
Background (hidden) Groups
DMO Individual Call
DMO Group Call
DMO Emergency Call
DMO Intelligent Emergency Call
TMO/DMO Independent Volume Control

**** Through use of Sepura pseudo keyboard text entry
Data Services and Applications

Status Messaging (in TMO & DMO)
SDS Messaging (in TMO & DMO) ****
Concatenated SDS Messaging ****
Multi-slot Packet Data
TETRA Pager and Call Out
WAP Browsing
Radio Applications
Image & Map Storage on Memory Card
Lone Worker Feature
Missed Event Application, indicator and softkey

**** Through use of Sepura pseudo keyboard text entry
Location Based Services

GPS Integrated Option
GPS Based Compass
Over The Air GPS reporting using the following protocols: ETSI Location Standard Reporting (LIP), NMEA and Sepura Compact Messaging

Security Services

Authentication
Class 1, 2 and 3 TETRA Security
Air Interface Encryption**
TEA1/2/3/4 Supported **
SMART Card E2E Encryption Support **
BOS and Sectra smart card support **
E2E Encryption Support **

** Availability is subject to export licence
Connectivity

TETRA V+D
PEI Data via USB Data Cable
High Speed Interface for Feature-rich Audio Accessories
Audio/Data Connection via Rugged Side Connector (RuSC)

Accessories

Stud & Belt Attachments
Leather Case
Rugged Cases
Rugged RSM
Rugged 80mm Chest-Mounted PTT
Rugged Throat Mic
Rugged Skull Mic
Rugged Overhead Dual Ear Defender-Style Headset & Boom Mic
Single-Sided Ear Defender-Style Helmet-Attached Earphone & Boom Mic
Lightweight Behind-The-Head, Single-Sided Headset & Boom Mic plus PTT
Hurricane-Style, Lightweight Direct-Connect Headset & Boom Mic Plus In-Line PTT
USB Data Lead

Dimensions

Height: 139mm
Width: 61mm/54mm
Depth: 44mm

Frequency Bands

380-430MHz – STP8X138
407-473MHz – STP8X140

Power Supply

7.4V (nominal) Lithium Polymer Battery Pack
Intelligent Reporting Battery
1400mAh Battery

Display and User Interface

Large 30x38mm Active LCD Area
Hi Resolution display (176 x 220 pixels)
Transflective TFT Display, 262K colours
Normal, Large & Very Large Mode Text
8 Configurable Soft Keys
2 context keys
Call History
Phone Book (2000 entries)
9900 Talkgroups in TMO/DMO
5000 Multi-Level Talkgroup Folders
Intelligent Search Facility
Quick Groups
Transmit Inhibit with on/off Status messaging
Fixed & definable Scan Lists
Remaining Charge Time Indication
Missed Call Indicator
Large tactile keypad, capable of operation with thick ‘Fire-ground’ gloves

DMO Repeater Services (licence required)

DMO Voice Repeated
DMO Tone Signalling Repeated
Group Status & SDS Repeated
Type 1A Efficient Operation over one Frequency Channel
Presence Signal Support
Emergency Call
Monitoring & Participation in Calls
