• Frequency Coverage: All amateur bands in the 1.8-29.7MHz range,(incl. WARC)
extensions and/or changes on request.
• Power Output: 1400 W PEP or 1000 W continuous carrier.
• Intermodulation Distortion: Better than 35 dB below rated output.
• Hum and noise: Better than 40 dB below rated output.
• Harmonic Output Suppression: Better than 50 dB below rated output.
• Input and Output Impedances:
– nominal value: 50 Ohm unbalanced, UHF (SO239) type connectors;
– input circuit: broadband, VSWR switching);
– Bypass path VSWR < 1.1:1, 1.8-30MHz continuously, 100 W maximum; – Output (antenna) impedance matching capability: VSWR up to 3:1 • Protection circuits:Ia>1000mA,Ig1>350mA,TMP>75C,SWR>3
• RF Gain: 11dB typically, frequency response < 1dB (80-100 W drive power for
• Primary Power: 220-240 V AC, 50-60 Hz, single phase, 2300 VA.
• Complies with CE safety and electromagnetic compatibility requirements.
• FAN :built in 230V/13W AC fan PAPST type 4605,12V/0.15A DC fan.
• Size & Weight : WxDxH: 410x340x185mm, 25kg
• Operating environments:
– temperature range: 0…+50 degs.Celsius;
– humidity: up to 95% @ +35 degs.Celsius.
– height: up to 3000m above sea level without output deterioration
