RF Linear amplifier coverd 1.8-30MHz amateur bands , using Chinese FU728F ceramic tetrodes working at Class AB1
Driving power:30-40W output:2000W ;
Driving power :60-70W output:2600W ( no recommend) .
3rd Order: -34dbc
Protection:exceed anode temerture;exceed current(screen and anode);over drive; SWR.
Heavy duty band switch and heavy duty HV transformer, independent...
The ACOM3x2000A is a HF power splitter / combiner which is a passive device designed to sum the outputs of three HF linear amplifiers into a common load while the amplifiers are driven by a single exciter. There is no difference from the operation of a three times more powerful single amplifier.
For proper operation, the combiner requires three amplifier outputs having equal amplitudes...
The ACOM 2000A Automatic HF Linear Amplifier is the world's most advanced HF amplifier designed for amateur use. The ACOM 2000A is the first amateur HF amplifier to include both fully automatic tuning and sophisticated digital control capabilities. This revolutionary new amplifier delivers maximum legal power in all modes and operates on all HF amateur bands.
A New Standard in Amplifier...
Easy to operate
The TRI is a powerful tuning aid that, together with the automatically controlled input attenuator, helps the operator to quickly and precisely match the antenna impedance to the optimum tube load impedance (5-10 seconds typically). The auto-operate function (when enabled) maintains the amplifier in the OPERATE mode for you, thus avoiding unnecessary manual operations.
FlexRadio 1500W Solid State Amplifier (Power Genius XL™)
The Power Genius XL is a 100% duty cycle, legal limit (1500W) 1.8-54 MHz RF amplifier intended for both amateur and government use. It incorporates a pair of modern BLF188 LDMOS transistors that are individually capable of 1.5 kW thus providing plenty of headroom for lowest IMD and spurious output. Efficiency and spurious performance...
RM Italy HBF 1000 Automatic Low-Pass Filter, 1.8-55mhz, 1000W.
The HBF 1000 is a high power low pass filter, it's designed to be used with a transceiever or amplifier to reduce the unwanted harmonics.
Covering all HAM Bands 1.8 to 55 Mhz
High Input Power 1000 Watts
10 Five pole filters with automatic or manual insertion
Cut-Off frequency: 2-4-7.5-11-15-19-22-26-30-55 Mhz
Large LCD display...
Temperature protection, overcurrent protection, input and output detection, high and low level, transistor, PA and ATU-through can be switched, only you need to enter 5W, 30MHz or less 120W, 50MHz 100W.
No more details yet. Stay tuned.
Chinese HF power amplifier SSB CW 1000W MOSFET VRF2933 copper and heat sink no LDMOS
HF power amplifier 1000W with modern MOSFET transistors VRF2933.
See Youtube video about this MOSFET VSWR ruggedness https://www.youtube.com/watch?v=bMEsEATudgM
Assembled and tested PCB with matched quad of transistors VRF2933 - 1000W output.
Transmission line output transformer on 43 material cores.
