Tag " SWL"

Experimental Shortwave Receiver with Touchscreen. Device properties: IF 10.7 MHz 455 KHz with Frequency- Preselector. Dimensions & Weight: Height: 11 cm Depth: 18 cm Width: 30 cm Weight: 1.4 kg http://youtu.be/uR5INb7_9BE The slightly smaller version of the swRX in which the band and frequency steps were outsourced to buttons for faster access. MODULATION, SPAN and ATT can be selected...


Continue Reading »

RDF Products DFR-1200B Wideband Radio Direction Finding Receiver. The RDF Products Model DFR-1200B is a compact, self-contained wideband HF/VHF/UHF DF receiver and bearing processor/display combo designed for both mobile and fixed-site DF applications. Frequency coverage is from 100 kHz to 3,000 MHz, limited only by the accompanying DF antenna. Comprising the DFP-1000B DF Processor/ Display...


Continue Reading »

Receives HF: 160m – 10m Amateur (Ham) Radio & AM International Broadcast Bands VHF: FM broadcast, Aircraft Band, Amateur, Marine, NOAA Weather Radio UHF: GMRS & FRS (family radio service) Frequency Coverage and Modes: MW-HF Continuous Coverage: 500 kHz - 30.000 MHz Amateur Band Selections: 160m – 10m CW-SSB auto-selection with Mode override (AM-CW-SSB) Auto-Filter Width...


Continue Reading »

Photo by STAMPFL Photo by STAMPFL Photo by STAMPFL This is Experimental Shortwave HF band receiver (130kHz to 30MHz) with AM-FM-USB-LSB-CW mode and including sensor screen pad. The hardware designed by HB9KOC. The software developed by HB9QN. Some details you can see on YouTube video below: http://youtu.be/q4Q_-6a6Kbg Link


Continue Reading »

Date:Nov 11, 2012 Time: 15:30 GMT Mode: USB Freq: 14 MHz Callsign: W6CCP http://www.cqdx.ru/blog/audio/W6CCP_LP_20m_SSB_11nov12_1530z.mp3


Continue Reading »

Very compact portable scanner for the road trip. The VR-160 has a solid aluminum die-cast chassis and a crisp LC matrix display. The receiver covers 100kHz up to 1299.995MHz continuously, no gaps. Receive modes are AM, AFM and WFM. The size of the scanner is the same as that of the Yaesu handheld radio VX-3E, using some optional accessories from this radio as well. The VR-160 hand scanner features...


Continue Reading »

High Performance IF-Receiver 0,04 MHz - 32 MHz MDS - 134 dBm = 0.03 μVolt sensitivity MDS = (Minimum Detectable Signal 3 dB above noise) Very high IP3: +29dBm (High-IP) 16 kHz crystal filter 10 pol roofing filter incl. notches Displayed on 24 kHz spectrum width at a sample rate of 48 kHz Dual 16 bit ADC, for 2 signal levels as RX and DX channel Easy Plug & Play Installation LSB,...


Continue Reading »
