The ZT-2R+ is one of Zastone’s newly launched miniature dual band, dual standby handheld wireless walkie talkies. With an aluminum housing, this hand held radio is shock proof and durable. With its anti-slip design, the grip is comfortable. With a 0.5-999Mhz wide band signal receiver, it is easy to hear communications coming through the walkie talkie. This ZT-2R mini walkie talkie can meet your needs, as it has over 1300 memory channels with sailing, shortwave and weather related channels. It easily supports HAM technology, making this a popular preferred product.
1. Miniature dual band handheld transceiver
2. 0.5-999Mhz Wide Receive Band
3. Over 1300 memory channels
4. Sailing, shortwave, weather channel
5. CTCSS and DCS codec
6. Tone scan and independent tone mode
7. WIRES connection shortcuts
8. Rugged aluminum housing
9. Automatic Repeater Shift (ARS)
10. Dual tone multi-frequency
11. Automatic power saving
12. Busy channel lockout
Frequency Range Wide Receiver Band List(RX List)
BC Band 0.540-1.8 MHz
SW Band 1.800-30MHz
50MHz Ham Band 30.000-79(59)MHz
FM Band 76(59.000)MHz-108 MHz
Air Band 108.000-137.000MHz
144MHz Ham Band 137.00-174.000MHz
VHF-TV Band 174-222.000MHz
Action Band 222-420.000MHz
430MHz Ham Band 420-470.000MHz
UHF-TV Band 470-800(729).000MHz/(757-774MHz)
Action Band2 800-999.000MHz(USA Cellular Block)
TX & TX Frequency
Channel NO. 1300
Operating Voltage 3.6V
Temperature Range -20°C~+60°C
Frequency Stability ±5ppm
Weight (g) 132
Output Power 1/1.5/2/3W
Spurious Radiation < -60 dB
Adjacent Ch. power < -60 dB
CTCSS/DCS deviation < 5KHz Audio Distortion ≤5% SNR >35 dB
