The linear amplifier OM1000+ is designed for all short wave amateur bands from 1.8 to 29 MHz (including WARC – bands) + 50 MHz and all modes. It is equipped with a ceramic tetrode GS-23B.
Frequency coverage: Amateur bands 1.8 – 29.7 MHz including WARC + 50 MHz
Power output: 1200+W PEP in SSB, 1000W CW on HF bands,
1000W PEP SSB, 800W CW on 50 MHz,
The high power combiner OM10C is designed for all short wave amateur bands from 1.8 to 29.7 MHz and maximum 10kW PEP output power.
Frequency coverage: 1.8 – 29.7 MHz continuous
Power rating: 10 kW PEP or continuous carrier into a matched load (VSWR below 1.2:1). Reduce the output at increased VSWR, linearly down to 5 kW at VSWR up to 2:1
Input impedance: 50 Ohm unbalanced, input UHF SO239...
Five inch (5”) (108x65mm) high resolution color display, 800x480 pixels and 24-bits colors.
The final stage uses field effect (MOSFET) transistors type BLF188 from NXP, designed to withstand high mismatch (SWR) at the output and intended for operation in aerospace, industrial, mobile, and radio broadcast applications.
Compatible with all transceiver models available...
300W • -60dB
Powerful: solidc 1.5kW in on on all modes.
Very Light: about 10 kgs (about 22 lbs).
Very Small: H 12, W 28, D 36 cm. (4.72" X 11.2" X about 17", connectors included).
Wide Frequency Coverage: 1.8 mHz to 54 mHz, including WARCs.
Where permitted: 60m. full power and 300W on 4m. (70mHz).
Internal Switching Power Supply with Power Factor Correction.
RF Sensing 1000 Watt Amplifier covering 160m to 6m bands with LCD touch-screen display to control the amplifier.
Output Power 1000 Watts PEP CW ICAS
Frequency range 1.8 to 54 MHz
Color Touch Screen allows access to all functions
Output 3 RF SO-239
ALC Exciter Power Control
Gain 14 db
RF Sensing Auto Band Switching
RF Output Vacuum R/T Switching
Power supply: Internal...
Photo by Elecraft
New KPA1500 solid-state amplifier won’t take over your entire desktop: it’s just 4.5 x 13.5 x 11.5” (HWD; 11.5 x 34 x 29 cm). The lightweight companion power supply can be placed on the floor or in any other convenient location.
The KPA1500 was designed with the serious operator in mind. Its no-nonsense front panel shows all important parameters at a glance, with a high-contrast...
PowerGenius XL™ is a true legal limit, all mode, HF -6m solid state amplifier in a small lightweight package incorporating the very latest in LDMOS transistor technology.
PowerGenius XL obsoletes those heavy and expensive to maintain tube amplifiers even in the most demanding DX and contest operations. Born of the collaboration between Sky Sat’s 403A Signature Laboratory in Europe and Austin,...
The automatic linear amplifier OM2000A+ is designed for all short wave amateur bands from 1.8 to 29 MHz (including WARC bands) + 50 MHz and all modes. It is equipped with an FU-728F ceramic tetrode. Has a LAN connection for remote operation, scroll down for more information on this and a link for free software download.
Specifications of the OM-2000A
Frequency coverage: Amateur bands...
