Frequency range: 1.8 ~ 30Mhz
Range of 45 ~ 55? input impedance
Initial tuning range of 5 ~ 30W power
Operating power range of 5 ~ 150W / PEP
SSB mode 5 ~ 100W / CW / FM tuner first time non-continuous mode, 1 to 8 seconds for 0.5 seconds
Memory tuning frequency 8000 range of 12.5 ~ 500? match
Frequency detection accuracy ± 1.5KHz (CW mode)
Matching inductor range 0 ~ 24.86uH (256 level)
Matching capacitance range 0 ~ 3908pF (256 level)
Power: 13.8V DC
Current Size 24X 20 X 6 CM
Weight 1780 g
Price: $156 USD
HyEndFed 5 band for 80,40, 20, 15, 10 meter band
HyEndFed 5 band for 80,40, 20, (15) and 10 meter.
Max. Power : 200 watt PEP.
Length : 23 meter.
Enclosure : Polycarbonate IP67, 100% UV resistant.
SO239 Connector : Silverplated.
10-40 Meter Coaxial Alpha Loop
The 3+ foot high and wide Coaxial Alpha Loop Antenna is perfect for those operating Condo, SOTA, Beach, RADAR, or any place you need a High-Q directional HF antenna with low noise capabilities designed...
Bonito Loop ML-200
The Bonito ML-200 is a wide band active antenna for reception of long, medium and short waves as well as the lower VHF band. The antenna is is characterized by a small apcking size, low noise and excellent...
Comment for Chinese Automatic Antenna Tuner CG 202A
