Raspberry Pirate Radio. Weekend Projects – Raspberry Pirate RadioWatch this video on YouTube This simple hack turns your Raspberry Pi into a powerful FM transmitter! It has enough range to cover your home, DIY drive-in movie, a high school ball game, or even a bike parade (depending on the stragglers). PiFM software not only boldly…
Raspberry and SSTV project Introduction: In this project the Raspberry Pi with the PiCam is used as a wireless camera which can transmit images over long distances, usually tenths of kilometers. Images will be transmitted by amateur radio (ham-radio) using slow scan television (SSTV) on the 2 meter band (144.5 MHz). Since the Pi can…
EA3GCY ILER 40 / 4-5W QRP SSB Monoband Transceiver KIT. SPECIFICATIONS GENERAL: Frequency Coverage: VXO tuning 20 a 100KHz segment in 40M band (60-70KHz for better stability). Bandwidth range is selected according L6 value in the VXO circuit. Frequency Control: high stability VXO oscillator. Option A: two 12.031MHz. crystals (upper limit aprox. 7.105MHz) Opción B:…
The Microcode kit assembles into a versatile Morse Code reader capable of decoding and displaying audio Morse code signals from speeds of 10 words per minute (wpm) to over 40wpm. A sensitive integral microphone combined with a tunable bandpass active filter allow the Microcode to operate effectively by being placed near to a receiver’s loudspeaker.…
TT2A works at 7.030 and 14.060. However, crystal sockets are used in the kit, offering a more flexible frequency switching. Crystals ranging from 60m – 20m can be plugged in to work without altering the tank coil. Photo by Youkits Photo by Youkits WORKING ON OTHER HF BANDS The frequency range for BAND 1 is…
